- Degree approval standard : Based on our approval method
- Column, Arm x-frame material : Specially Alloy Steel
- Machine Drive Unit : Roller Bearing
- Use when small – size precision measuring
- Manual & CNC – operation
[Product Specification]
unit : mm
|
Model
|
MB-Z
|
MB-Y
|
H1
|
H2
|
B3
|
B2
|
B1
|
|
ATD1010
|
1000
|
1000
|
1886
|
210
|
473
|
2000
|
3267
|
|
ATD1212
|
1200
|
1200
|
2086
|
210
|
473
|
2000
|
3467
|
|
ATD1513
|
1500
|
1300
|
2386
|
210
|
473
|
3000
|
3567
|
|
ATD1815
|
1800
|
1500
|
2686
|
210
|
473
|
3000
|
3769
|
|
ATD2015
|
2000
|
1500
|
2886
|
210
|
473
|
3000
|
3767
|
|
ATD2520
|
2500
|
2000
|
3386
|
210
|
523
|
4000
|
3767
|
