Unbranded

AIMS-A

  • Payment
    T/T
  • MOQ
    Negotiable
  • Country of sale
    World Wide
  • PRICE
    • FOB

      Depend on quantity

ITEM SPECIFICS

  • Brand
    Unbranded
  • origin
    Republic of Korea
  • Size(Capacity)

AIMS-A

Business Information
The AIMS(Autonomous Interference Mitigation System) is an anti-jamming system eliminating the interference signal based on the array antenna offered by Navcours.The AIMS(Autonomous Interference Mitigation System)-A is an analog method system controlling the gain pattern of the array antenna based on the 4 element CRPA(Controlled Reception Pattern Antenna) and the Null Steering Algorithm where by controlling the antenna receiving pattern minimizing antenna gain from the direction of the interference signal entry provides the eliminating function of not only the narrowband but the broadband interference signals.
The AIMS-A replaces the digital method CRPA system with cost and size limitations easily applicable to ground weapons systems such as tanks and armored vehicles as well as diverse weapons systems such as ships and aircrafts. The AIMS-A especially is most suitable for time synchronization on mobile communication systems with an almost zero signal processing delay time.

Manufactured Products

160 x 160 x 65mm
Weight : below 1.8kg
12~36V / 15W
Frequency : GPS L1(1575.42 MHz)
Bandwidth : 10 MHz
VSWR : < 2.0
Noise Figure : < 2.5 dB
Gain : > 20 dB
IP1dB : -36 dBm
2.4GHz Bluetooth Interface
4 Array GPS Antenna
TNC Female Connector
Power Supply thru RF Connector
BlueTooth Supports Monitoring & Control
5/8”Flange supports Easy installation
Null Depth > 50dB (for CW)
CW, AM, FM, Sweep CW, Pulse, AWGN

AIMS Test Results
