Microwave Frequency | 24.15GHz |
Scope(Length of Protection zone) | Max. 200m |
Lobe Witdh | 1.5m(Max) |
Lobe Height | 1.2m(Max) |
Range of Power Supply Voltage | 9~30Vdc |
Current Consumption | 35mA |
Relay Contacts Values | N.C 28 Vdc, Maximum current 0.1 A |
Alarm Period | 3 Sec (Max.) |
Tamper Switch | N.C 28 Vdc Maximum current 0.1 A - open when cover is removed |
Detection Speed (Target Velocity) | 0.1 ~ 10 m/sec |
Remote testing | Built-in self-test generator simulates actual intrusion signals |
Flatness of Ground | Approx. 0.3 m |
Maximum Height of Grass on the ground | 0.3 m |
Maximum Height of Snow on the ground | 0.5 m |
Alarm Output - Switching over of relay Contacts for the time | Minimum 3 Sec |
Dimensions of Unit (trans./rec.)W/O braket | 211x138x105mm |
Weight(T,Rand Accessories) | 1.2Kg |
Operating Temperature Range | -40°C ~ +85°C |
Interface | RS-485 |
Weather Proofing | •All openings with gasket and sealed •Conformal coated circuit board |
